200 ton Aida NC1-2000(2) Used Single Point Gap Mechanical Metal Stamping Press For Sale, Year 20

Manufacturer

AIDA

Category

Presses

Type

PRESSES, GAP FRAME, (Single Crank)

Stock

2921

Model

Aida NC1-2000 (2)E

Dealer Location

Michigan

Request a Quote
View Contact Information

Spec Sheet

Tonnage - 220
Stroke - 9.84 inches
Shut Height - 20.14 inches
Adjustment - 4.33 inches
Bed Size - 54.7 x 33.1
Ram Area - 34.6 x 25.6
SPM - 25-50 VSPM


Standard Specifications
Aida Press Model NC1-2000 (2) E
Single Point Mechanical Metal Stamping OBS Press
200 ton Metric Capacity
220 ton US Capacity
9.84" Stroke
24.8" Shut Height over Bed
17.72" Die Height over Bolster
4.3" Motorized Adjustment
54.7" LR x 33.1" FB Bed Area
34.6" LR x 25.6" FB Slide Area
25-50 VSPM

Equipment and Features
Wet Clutch and Brake
Air Counterbalances
Recirculating Lube System
Vibro Floor Mounts
T-Slotted Ram and Bolster
Hydraulic Overloads
20 HP Main Drive Motor
Motors and Controls

This used 200 metric ton Aida Press can be seen under power in the S&G Press Livonia Michigan Warehouse upon request!

The Aida Press Model NC1-2000 (2) E is a single-point mechanical metal stamping press. Designed for Outside Blanking and Sizing (OBS) operations, this press is ideal for high-volume production of metal components. Its robust construction and advanced features ensure efficient and reliable performance. This press is ideal for manufacturers seeking precision and productivity in their stamping processes.

Used Single Crank Mechanical Metal Stamping Gap / OBS Aida Press For Sale
