60" x 218.75" T-Slotted, 10" Thick, 5 T-Slots, Cast Iron, NEW, #43432

Manufacturer

Category

Tables

Type

TABLES, FLOOR & LAYOUT PLATES, (Radial & Boring Mill)

Stock

43432

Model

Cast Iron

Dealer Location

New York

Request a Quote
View Contact Information

Spec Sheet

Reference #43432
Floor Plate, T-Slotted 60" x 218.75" x 10" Cast Iron, NEW

FEATURES:
Cast Iron Construction
Matched

CAPACITY:
Width ................................. 60"
Length ................................ 218.75
Thickness ............................. 10"
Number of T-Slots, Longitudinal ....... 5
Distance Between T-Slots ............. 12"
T-Slot Depth .......................... 2"
T-Slot Width, Top ..................... 1"
T-Slot Width, Bottom .................. 1.75"
Approximate Weight Per Each Plate ..... 15,000 Lbs

EQUIPPED WITH:
Matched
T-Slotted

NOTE:
Cost Is Per Each Plate

NOTE:
Delivery Approximately 5 Months From Order
