UTUBE NUMBER: 2419
MANUFACTURER: KENT / TESGO
MODEL NUMBER: 1 R0C10169
SERIAL NUMBER: BM-3-1000
SPECIFICATIONS:
Maximum Tube Length: 24" (609 mm)
Minimum Tube Length: 12" (304 mm)
Maximum Tube Diameter: 4" (101 mm)
Minimum Tube Diameter: 1/2" (12.7 mm)
Maximum Bar Diameter: 2.4" (60.9 mm)
Minimum Bar Diameter: 3/8" (9.52 mm)
Profile Section: 3/8" x 3/8" to 2" x 2"
Output: 3,500 Maximum Pieces per Hour
Brush Length: 36"
Brush O.D.: 10"
Motors: (2) ABB 11 KW A/C
EQUIPPED WITH:
Push Buttons
Powered Exit Conveyor w/Drop Bin & Digital Counter
Infeed Table
Brush Wear Adjustment
OVERALL DIMENSIONS: 10′ x 12′ x 6-1/2′
APPROXIMATE WEIGHT: 5,500 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
