14 Stand x 1-1/2" x 6" TISHKEN #14 HMW 1-1/2 Rollformer

Manufacturer

TISHKEN

Category

Roll Formers

Type

ROLL FORMERS

Stock

3267

Model

14 HMW 1-1/2

Dealer Location

Ohio

Request a Quote
View Contact Information

Spec Sheet

UTUBE NUMBER: 3267
MANUFACTURER: TISHKEN
MODEL NUMBER: 14 HMW 1-1/2
SERIAL NUMBER: 553-5161

SPECIFICATIONS:
Line Direction: Right to Left
Number of Stands: 14
Spindle Diameter: 1-1/2"
Roll Space: 6"
Horizontal Center: 9"
Vertical Adjustment: 4-1/2" – 5-1/2"
Base Top to Center Lower Spindle: 4-1/2"
Spindle Key Size: 1/4"
Line Speed: 100 FPM
Maximum Thickness: .078"

EQUIPPED WITH:
10 HP Motor with Vari Speed Manual Drive
Start, Stop, Run, Jog Buttons

NOTE: Missing 3 Spindles & 1 Outboard Stand

OVERALL DIMENSIONS: 12′ 6" x 4′ x 6′
APPROXIMATE WEIGHT: 7,200 Lbs.
LOCATION: Universal Warehouse, Perrysburg, Ohio
