Bystronic BySmart Fiber 3015, 6KW Fiber Power Source, Auto Nozzle Changer 60" x 120", Dual Pallet, Low Hrs., 2019 #32945

Manufacturer

BYSTRONIC

Category

Laser Cutting

Type

LASERS

Stock

32945

Model

BySmart Fiber 3015

Dealer Location

New York

Request a Quote
View Contact Information

Spec Sheet

Reference #32945
Bystronic BySmart Fiber 3015 6KW Laser

FEATURES:
ByVision Control with Touchscreen
Fiber 6000 Laser Source
Automatic 40 Position Nozzle Changer
Automatic Pallet Shuttle Table
Chiller
Dust Collector

CAPACITY:
Maximum Laser Output .................. 6000 Watts
Maximum Cutting Thickness (Steel) ..... 1"
Maximum Cutting Thickness (Stainless).. 1.18"
Maximum Cutting Thickness (Aluminum) .. 1.18"
X-Axis Cutting Area.................... 122"
Y-Axis Cutting Area ................... 60"
Z-Axis Cutting Area ................... 4"
Positioning Accuracy .................. +/- .004"
Max. Work Piece Weight ................ 2,425 Lbs.
Max. Pos. Speed Parallel Axis X,Y ..... 3,937 IPM
Max. Positioning Speed Simultaneous.... 5,511 IPM
Overall Length of Machine ............. 413"
Overall Width of Machine .............. 272"
Approximate Shipping Weight ........... 26,015 Lbs.

EQUIPPED WITH:
ByVision Control with Touchscreen
Fiber 6000 Laser Source
Automatic 40 Position Nozzle Changer
Automatic Pallet Shuttle Table
Chiller
Dust Collector

NOTE:
Inspect In Plant Under Power
Low Hours, Only 3,554 Cutting Hours, Machine is in Excellent Condition
