2006 Haas VF-2D Vertical Machining Center (#4840)

Manufacturer

Category

Machining Centers

Type

MACHINING CENTERS, VERTICAL, CNC (Incl. Pallet Changers)

Stock

None

Model

None listed

Dealer Location

Florida

Request a Quote
View Contact Information

Spec Sheet



 30” X 16” X 20” Vertical Machining Center with Haas CNC Control with USB Port, Brushless Servos on All Axis, (2) Speed Gear Box, Programmable Coolant, Quick Code, Rigid Tap, Twenty Position Automatic Toolchanger, Chip Auger, Telescopic Way Covers, Air Gun, (6) Leveling Pads, BIJUR Automatic Lubrication System, 20 HP Vector Dual Drive, Through Spindle Coolant, Rigid Tapping, Coordinate Rotation and Scaling, High Speed Machining, M19 Spindle Orientation, Haas HRT210 4th - Axis Rotary Table, Machine Manuals, External Coolant Tank & Coolant Pump.

GENERAL SPECIFICATIONS
Table Size:                36” X 14”
X - Axis Travel:            30”
Y - Axis Travel:            16”
Z - Axis Travel:            20”
Spindle Nose to Table:        4 - 24”
Maximum Weight on Table:    1,800 Lbs
Spindle Power:            20 HP
Spindle Speeds:            0 - 15,000 RPM
Spindle Taper:            BT-40
Tool Changer Capacity:        24 Positions
Rapid Traverse Rates:        1,000 IPM
Approximate Dimensions:        90” X 80” X 100”
Approximate Weight:        9,500 Lbs

INCLUDES: Haas CNC Control with USB Port, Brushless Servos on All Axis, (2) Speed Gear Box, Programmable Coolant, Quick Code, Rigid Tap, Twenty Position Automatic Toolchanger, Chip Auger, Telescopic Way Covers, Air Gun, (6) Leveling Pads, BIJUR Automatic Lubrication System, 20 HP Vector Dual Drive, Through Spindle Coolant, Rigid Tapping, Coordinate Rotation and Scaling, High Speed Machining, M19 Spindle Orientation, Haas HRT210 4th - Axis Rotary Table, Machine Manuals, External Coolant Tank & Coolant Pump.


***We strongly encourage personal inspection of all pieces of used equipment***
***All Price, Location and Specifications Subject to Change without Notice***
