2007 Ficep 1001DZB Beam Drill / Saw Line (#4562)

Manufacturer

Category

Fabricating Machines

Type

FABRICATING EQUIPMENT

Stock

None

Model

None listed

Dealer Location

Florida

Request a Quote
View Contact Information

Spec Sheet



40" X 17-3/4" Beam Drill & Saw Line with Ficep CNC Controls, (5) Position Tool Changer, Ficep 1045 BH Horizontal Saw, 65' Infeed and Outfeed Roller Tables

GENERAL SPECIFICATIONS
Drilling Capacity:
Drilling Heads: 1
Spindles Per Head: 1
Max Hole Diameter: 2"
Spindle Rotation Motor: 15 HP
Spindle Speeds: 180 - 2500 RPM
Sawing Capacity:
Capacity at 90° (Min): 3-1/8" X 3/8"
Capacity at 90° (Max): 40" X 17-3/4"
Capacity at 60°: 13-3/4" X 13-3/4"
Capacity at 45°: 24-3/8" X 17-3/4"
Blade Size: 1.61" X 0.051"
Motor: 7.5 HP
Programmable Blade Speed: 65 - 328 FPM
I - Beam:
Min Depth: 3-1/8"
Max Depth (Saw): 40"
Max Width (Drill): 44"
Channels:
Min Depth: 3-1/8"
Max Depth (Saw): 40"
Max Depth (Drill): 44"
Flange Min Height: 1-3/4"
Flange Max Height: 11-3/4"
Angles:
Min Leg Height: 3-1/8" X 3-1/8" X 3/8"
Max Leg Height: 10" X 10" X 1-9/16"
Flats:
Min Width: 4"
Max Width (Saw): 40"
Max Width (Drill): 44"
Square Tube:
Min Size: 3-1/8" X 3-1/8"
Max Size: 17-3/4" X 17-3/4"
Rectangular Tubes:
Min Size: 3-1/8" X 1-9/16"
Max Size (Saw): 40" X 17-3/4"
Max Size (Drill): 44" X 17-3/4"
All Beams:
Max Thickness (Drilling): 3"
Max Length: 60'
Min Length: 8'

INCLUDES: Ficep CNC Controls, (5) Position Tool Changer, Ficep 1045 BH Horizontal Saw, 65' Infeed and Outfeed Roller Tables


***We strongly encourage personal inspection of all pieces of used equipment***
***All Price, Location and Specifications Subject to Change without Notice***
