Keyence IM-6225T Portable Shop Floor CMM System, New 2017, Low Hours, #31598

Stock

31598

Model

IM-6225T

Dealer Location

New York

Spec Sheet

Reference #31598
Keyence IM-6225T Portable Shop Floor CMM System

SPECIFICATIONS:
Field of View ......................... 3.94" x 7.87"
Measuring Range ....................... 0-2.36"
Measurement Positioning Accuracy ...... +/-0.003"
Measurable Area (Standard Probe) ...... 1.77" x 3.74"
Measurable Area (Wide-Range Probe) .... 3.74" x 3.74"
X-Axis Moving Range (Electric )........ 3.94"
Z-Axis Moving Range (Electric) ........ 1.18"
Withstand Load ........................ 2 kg
Min. Display Unit, Distance .......... 1 um

EQUIPPED WITH:
10.4" LCD Monitor
1" 6.6 Mega Pixel Monochrome CMOS
Double Telecentric Lens
