32 TON BLISS HORN PRESS: STOCK #19349

Manufacturer

BLISS

Category

Presses

Stock

19349

Model

0032

Dealer Location

Ohio

Spec Sheet



SERIAL ............................ H28066
MODEL ............................. 40
STROKE ............................ 4"
SHUT HEIGHT (SDAU) ................ 6" BED UP, 18" BED DOWN
SLIDE ADJUSTMENT................... 2 1/2"
STROKES PER MINUTE................. 115
BED AREA .......................... 21" FB X 24" LR
SLIDE AREA ........................ 8 7/8" FB X 6 3/4" LR
HORN HOLE ......................... 4" DIA
SHUT HEIGHT OVER HORN HOLE ........ 3 1/2"
THROAT ............................ 10"
BOLSTER ........................... 2" THICK
EQUIPPED WITH:
AIR ACTUATED MECHANICAL CLUTCH .... YES
MECHANICAL BAND BRAKE ............. YES
FLYWEEL ........................... YES
MANUAL SLIDE ADJUSTMENT ........... YES
DUAL PALM BUTTONS ................. YES
FOOT PEDAL ........................ YES
MANUAL LUBE ....................... YES
MOTOR ............................. 3 HP / 3 PHASE
