30' BULLARD 'CUTMASTER' VERTICAL TURRET LATHE: STOCK #61560

Manufacturer

Category

Lathes

Type

LATHES, VERTICAL TURRET

Stock

61560

Model

30 CUTMASTER 4 JAW

Dealer Location

Ohio

Request a Quote
View Contact Information

Spec Sheet



SERIAL ............................... 16115
MODEL ................................ 30 CUTMASTER
CHUCK ................................ 30" 4 JAW
MAXIMUM SWING ........................ 44"
SWING WITH SIDE HEAD IN POSITION ..... 34"
MAXIMUM UNDER RAIL ................... 25"
MAXIMUM UNDER TURRET FACE ............ 36"
TABLE SPEEDS ......................... (20) 6.16 TO 225 RPM
FEEDS ................................ (16) .026 TO .500IPR
5 POSITION TURRET HEAD ON RAIL ....... YES
HORIZONTAL TRAVEL OF TURRET HEAD ..... 36"
VERTICAL TRAVEL OF TURRET HEAD ....... 26"
TURRET HEAD SWIVEL (EITHER WAY) ...... 30 DEGREE
HORIZONTAL TRAVEL OF SIDE HEAD ....... 21"
VERTICAL TRAVEL OF SIDE HEAD ......... 25-1/4"
VERTICAL TRAVEL OF RAIL .............. 15"
PENDANT CONTROL, ONE SHOT LUBE, ...... YES
RAPID TRAVERSE ALL DIRECTIONS ........ YES
3 AXIS DIGITAL READOUT ............... SONY
MOTOR ................................ 30 HORSEPOWER
