KEARNEY & TRECKER PLAIN HORIZONTAL MILL: STOCK #73118

Manufacturer

Category

Air Compressors

Type

AIR COMPRESSOR ACCESSORIES

Stock

73118

Model

None listed

Dealer Location

Ohio

Request a Quote
View Contact Information

Spec Sheet



SERIAL ................................ #6-3261
MODEL ................................. 3K PLAIN
WORKING SURFACE OF TABLE .............. 64" X 15 1/2"
SPINDLE SPEEDS ........................ (24) 15 TO 1500 RPM
CROSS AND LONGITUDINAL FEEDS .......... (32) 1/4 TO 60 IPM
VERTICAL FEEDS ........................ (32) 1/8 TO 30 IPM
LONGITUDINAL TRAVEL ................... 34"
CROSS TRAVEL .......................... 12"
VERTICAL TRAVEL ....................... 18"
TAPER IN SPINDLE ...................... #50NS
DISTANCE CENTER OF SPINDLE TO TABLE ... 0" MINIMUM, 18" MAXIMUM
RAPID TRAVERSE ........................ 150 IPM
DUAL CONTROLS
COOLANT
10 HP/3/60/220-440V/1750 RPM MAIN MOTOR
OVERALL DIMENSIONS - 7' X 7' X 5'6"
WEIGHT - 8,000 LBS APPROXIMATE
