CINCINNATI MODEL #6 HORIZONTAL MILL: STOCK # 67480

Manufacturer

Cincinnati

Category

Milling Machines

Type

MILLERS, VERTICAL

Stock

67480

Model

6

Dealer Location

Ohio

Request a Quote
View Contact Information

Spec Sheet



MODEL ............................... 650-20
WORKING SURFACE OF TABLE ............ 104-1/2" X 20"
SPINDLE SPEEDS ...................... (24) 14 TO 1400 RPM
LONGITUDINAL & CROSS FEEDS .......... (32) 3/8 TO 90 IPM
VERTICAL FEEDS ...................... (32) 3/32 TO 22-1/2 IPM
LONGITUDINAL TRAVEL ................. 60"
CROSS TRAVEL ........................ 18"
VERTICAL TRAVEL ..................... 20"
DISTANCE SPINDLE TO TABLE ........... 3/4" MINIMUM, 20-3/4" MAXIMUM
TAPER IN SPINDLE .................... #50 NS
POWER RAPID TRAVERSE ................ 150 IPM
DOVETAIL OVERARM .................... YES
AUTO LUBE & COOLANT ................. YES
MAIN MOTOR .......................... 50 HORSEPOWER
