#4L GISHOLT SADDLE TYPE TURRET LATHE: STOCK # 61838

Manufacturer

GISHOLT

Category

Lathes

Type

LATHES, TURRET, SADDLE TYPE

Stock

61838

Model

4L

Dealer Location

Ohio

Request a Quote
View Contact Information

Spec Sheet



SERIAL ............................ 3430X4
MODEL ............................. 4L
SWING OVER BED .................... 31-3/8"
SWING OVER CROSS SLIDE ............ 24-1/2"
SPINDLE NOSE TO TURRET FACE ....... 104"
SPINDLE SPEEDS .................... (24) 7 TO 395 RPM
LONGITUDINAL AND TURRET FEEDS ..... (16) .005 TO .176 IPR
CROSS SLIDE FEEDS ................. (16) .005 TO .008 IPR
CROSS SLIDING TURRET FEEDS ........ (16) .0025 TO .088 IPR
DIAMETER OF SPINDLE HOLE .......... 9-1/4"
CROSS SLIDING TURRET TRAVEL ....... 14-1/2"
CHUCK ............................. 24" 3 JAW
SPINDLE FORWARD/REVERSE ........... YES
SPINDLE JOG ....................... YES
HARD WAYS ......................... YES
RAPID TRAVERSE .................... YES
STEADY REST ....................... ROLLER TYPE
COOLANT WITH CHIP PANS ............ YES
MOTOR ............................. 40 HORSEPOWER
