3" PINES MODEL #2 HORIZONTAL TUBE BENDER: STOCK #52444

Manufacturer

PINES

Category

Tube Machinery

Type

TUBE BENDERS

Stock

52444

Model

3'

Dealer Location

Ohio

Request a Quote
View Contact Information

Spec Sheet



SERIAL NUMBER .................... 11245-64179
MODEL ............................ #2
EXTRA HEAVY PIPE IPS ............. 3"
NON FERROUS TUBING YP ............ TO 12,000 PSI 3-1/2" X .188
NON FERROUS TUBING YP ............ TO 25,000 PSI 3-1/2" X .120
STEEL TUBING YP .................. TO 40,000 PSI 3-1/2" TO .083
STEEL BAR ROUND YP ............... TO 40,000 PSI 1-7/8" DIA
MAXIMUM TUBE LENGTH .............. 20'9" OVER MANDREL APPROX
EXTENSION TABLE W/HYD PUSH CYCLE . 14'4"
MAXIMUM RADIUS ................... 12"
BENDING ARM ...................... 30"
BENDING ARM SPEED ................ 5.5 RPM
HYDRAULIC MANDREL EXTRACTOR ...... YES
(3) BUTTON PEDESTAL CONTROL ...... YES
8 POSITION DEGREE TURRET OF BEND SELECTOR
COUNTER CLOCKWISE ROTATION ....... YES
MOTOR ............................ 7-1/2 HORSEPOWER
