16 Stand x 2" x 8" TISHKEN #16MW2 Rollformer

Manufacturer

TISHKEN

Category

Roll Formers

Type

ROLL FORMERS

Stock

3853

Model

16MW2

Dealer Location

Ohio

Request a Quote
View Contact Information

Spec Sheet

Stock #3853
Serial #7629-557
Direction: R-L
Spindle Diameter: 2"
Roll Space: 8"
Horizontal Center: 12"
Adjustment: 5-1/2" - 7"
Base Top to Center Lower Spindles: 5"
Spindle Key Size: 3/8" Sq.
Max Height of Part: 2-3/4"
Max Thickness: .109"
Equipped With: Coolant Pump, Motor (440/3/60), Pushbuttons
Note: Missing 1 outboard stand
Overall Dimensions: 14' x 4' x 4'
Approx Weight: 12000 Lbs
Location: Perrysburg, Ohio
