8" X 18" KENT #KGS-818AHD AUTOMATIC HYDRAULIC SURFACE GRINDER: STOCK #11062

Manufacturer

KENT

Category

Air Compressors

Type

AIR COMPRESSOR ACCESSORIES

Stock

11062

Model

08 x 018 KSG-818AHD

Dealer Location

Ohio

Request a Quote
View Contact Information

Spec Sheet



SERIAL ............................... 89060304
MODEL ................................ KGS-818AHD
TABLE WORKING SURFACE ................ 8" X 18"
MAXIMUM TABLE TRAVEL ................. 19" X 10"
TABLE TO SPINDLE CENTER, MAXIMUM ..... 19"
LONGITUDINAL HYDRAULIC FEED RATES .... 16 TO 75 FPM
CROSS POWER FEED ..................... .004" TO .3" PER STROKE
RAPID CROSS FEED ..................... 35 IPM
AUTOMATIC DOWNFEED INCREMENT ......... .0001" TO .001"
HAND FEED PER REVOLUTION/GRADUATION .. .2"/.001"
SPINDLE MOTOR ........................ 1.5 HP 220/440/3/60
HYDRAULIC PUMP ....................... 1 HP 220/440/3/60
GRINDING WHEEL ( STANDARD WHEEL ) .... 7" X 1/2" X 1.25"

INCREMENTAL DOWN FEED ................ POWER
LONGITUDINAL & CROSS FEEDS ........... POWER
COOLANT SYSTEM ....................... YES
ONE SHOT LUBRICATION ................. YES
SPLASH GUARDS ........................ YES
HYDRAULIC UNIT ....................... YES
