EQUIPPED WITH Neutrofier II Magnetic Chuck Control (see pic) 8" x 20" Electro Magnetic Chuck Variable Chuck Control Auto Lube System Coolant System Splash gaurd backing

Manufacturer

Okamoto

Category

Machining Centers

Type

MACHINING CENTERS, VERTICAL, CNC (Incl. Pallet Changers)

Stock

Ez23418

Model

820A

Dealer Location

California

Request a Quote
View Contact Information

Spec Sheet

>Table Size: 8" x 20"
Longitudinal Table Travel: 25.59"
Max. Table Load: 440 Lbs.
Cross Saddle Travel: 9"
Max. Distance Under Wheel: 15.6"
Table Speed: 1- 83 FPM
Cross Saddle Feeds (Intermittent): 0.02"- 0.8"
Continuous Cross Saddle Feed: 4- 40 IPM
Automatic Spindle Downfeed Rate (Incremental): 0.0002"- 0.0015"
Rapid Vertical Spindle Rate: 19 IPM
Grinding Wheel Size: 8" x 1" x 1 1/4"
Grinding Motor Power: 2 HP
Machine Dimensions (L x W x H): 90" x 70" x 75"
Machine Weight: 3,600 Lbs.

EQUIPPED WITH
Neutrofier II Magnetic Chuck Control (see pic)
8" x 20" Electro Magnetic Chuck
Variable Chuck Control
Auto Lube System
Coolant System
Splash guard backing

Here is link to video of this machine running:
https://youtu.be/50iZ5YPYz3gor
