4390
320-185
Michigan
18" X 84" Working Surface Of Table
5' of Table Travel
7 1/2" Diameter Of Quill
#50 National Standard Taper In Spindle.
16 Spindle Speeds of 30-1200 RPM
1/4" - 150" IPM Table Speeds
300" IPM Rapid Speeds
5 HP Hydraulic Motor
1/2 HP Coolant Pump & Necessary Piping
20 HP Spindle Drive Motor
All Motors Are 220/440
Machine Connected for 440 W/110V Control Circuit
18.25" Max Height From Top Of Table To Center Of Spindle
Dimensions: Mill - 160"L x 80W x 75H , Electrical Cabinet 90"H x 48"W x 12"D
Approximate Shipping Weight: 16500 lbs.
